安装配件组套CLASSIC, FUTURA, FLEX, NOVA直接安装

商品号: 101476

1 x 104833 Reducer G1/8 male x G1/4 female

1 x 104837 Reducer M6 male x G1/4 female

1 x 104838 Reducer M8x1 male x G1/4 female

1 x 104840 Reducer M10x1 male x G1/4 female

1 x 104855 Extension 45 mm G1/4 male x G1/4 female

1 x 104823 Angle 45° G1/4 male x G1/4 female

安装配件组套STAR直接安装

商品号: 101477

1 x 104833 Reducer G1/8 male x G1/4 female

1 x 104837 Reducer M6 male x G1/4 female

1 x 104838 Reducer M8x1 male x G1/4 female

x 104840 Reducer M10x1 male x G1/4 female

1 x 104855 Extension 45 mm G1/4 male x G1/4 female

1 x 104823 Angle 45° G1/4 male x G1/4 female

1 x 109420 Support flange STAR G1/4 male x G1/4 female

安装配件组套CLASSIC, FUTURA, FLEX, NOVA含 1.5 米软管

商品号: 101481

1 x Reducer G1/8 male x G1/4 female (brass)

1 x Reducer M6 male x G1/4 female (brass)

1 x Reducer M8x1 male x G1/4 female (brass)

1 x Reducer M10x1 male x G1/4 female (brass)

1.5 m Heavy Duty hose up to +100 °C (with NBR lining and fabric insert)

2 x Hose connector G1/4 male for hose iØ 9.5 mm - push-lock (steel, zinc-plated)

1 x Mounting bracket CLASSIC, FUTURA, FLEX, NOVA 1-point G1/4 female (stainless steel)

1 x Angle 45° G1/4 male x G1/4 female (brass)

1 x Extension 45 mm G1/4 male x G1/4 female (brass)

安装配件组套STAR含 3 米软管

商品号: 101482

1 x Reducer G1/8 male x G1/4 female (brass)

1 x Reducer M6 male x G1/4 female (brass)

1 x Reducer M8x1 male x G1/4 female (brass)

1 x Reducer M10x1 male x G1/4 female (brass)

3 m Heavy Duty hose up to +100 °C (with NBR lining and fabric insert)

2 x Hose connector G1/4 male for hose iØ 9.5 mm - push-lock (steel, zinc-plated)

1 x Mounting bracket STAR Standard Duty 1-point G1/4 female (stainless steel)

1 x Support flange STAR G1/4 male x G1/4 female (brass / plastic)

1 x Angle 45° G1/4 male x G1/4 female (brass)

1 x Extension 45 mm G1/4 male x G1/4 female (brass)

安装配件组套CLASSIC, FUTURA, FLEX, NOVA标准载荷梁夹安装

安装配件组套CLASSIC, FUTURA, FLEX, NOVA标准载荷1点30mm梁夹安装

商品号: 110068

1 x 109685 Bracket 1-point G1/4 female

1 x 109957 Beam clamp 30 mm

1 x 113972 Purge connection with manual valve R1/4 male x G1/4 female

1 x 109849 Angle 90° R1/4 male x G1/4 female

2 x 101554 Hose connector G1/4 male for hose iØ 9.5 mm

1 m 101555 Heavy Duty hose

1 x 109953 Reducer R1/8 male x G1/4 female

1 x 109954 Reducer R1/4 male x G1/4 female

1 x 104840 Reducer M10x1 male x G1/4 female

安装配件组套CLASSIC, FUTURA, FLEX, NOVA标准载荷1点65mm梁夹安装含 1 米软管

商品号: 110069

1 x 109685 Bracket 1-point G1/4 female

1 x 109958 Beam clamp 65 mm

1 x 113972 Purge connection with manual valve R1/4 male x G1/4 female

1 x 109849 Angle 90° R1/4 male x G1/4 female

2 x 101554 Hose connector G1/4 male for hose iØ 9.5 mm

1 m 101555 Heavy Duty hose

1 x 109953 Reducer R1/8 male x G1/4 female

1 x 109954 Reducer R1/4 male x G1/4 female

1 x 104840 Reducer M10x1 male x G1/4 female

安装配件组套CLASSIC, FUTURA, FLEX, NOVA标准载荷2点30mm梁夹安装含 2 米软管

商品号: 110070

1 x 109686 Bracket 2-point G1/4 female

2 x 109957 Beam clamp 30 mm

2 x 113972 Purge connection with manual valve R1/4 male x G1/4 female

2 x 109849 Angle 90° R1/4 male x G1/4 female

4 x 101554 Hose connector G1/4 male for hose iØ 9.5 mm

2 m 101555 Heavy Duty hose

0,25 m 109695 Hose spiral guard 25 mm

2 x 109953 Reducer R1/8 male x G1/4 female

2 x 109954 Reducer R1/4 male x G1/4 female

2 x 104840 Reducer M10x1 male x G1/4 female

安装配件组套CLASSIC, FUTURA, FLEX, NOVA标准载荷2点65mm梁夹安装含 2 米软管

商品号: 110071

1 x 109686 Bracket 2-point G1/4 female

2 x 109958 Beam clamp 65 mm

2 x 113972 Purge connection with manual valve R1/4 male x G1/4 female

2 x 109849 Angle 90° R1/4 male x G1/4 female

4 x 101554 Hose connector G1/4 male for hose iØ 9.5 mm

2 m 101555 Heavy Duty hose

0,25 m 109695 Hose spiral guard 25 mm

2 x 109953 Reducer R1/8 male x G1/4 female

2 x 109954 Reducer R1/4 male x G1/4 female

2 x 104840 Reducer M10x1 male x G1/4 female

安装配件组套CLASSIC, FUTURA, FLEX, NOVA标准载荷网挂

安装配件组套CLASSIC, FUTURA, FLEX, NOVA标准载荷1点网挂含 1 米软管

商品号: 110072

1 x 109689 Bracket cage hanger 1-point G1/4 female

1 x 113972 Purge connection with manual valve R1/4 male x G1/4 female

1 x 109849 Angle 90° R1/4 male x G1/4 female

2 x 101554 Hose connector G1/4 male for hose iØ 9.5 mm

1 m 101555 Heavy Duty hose

1 x 109953 Reducer R1/8 male x G1/4 female

1 x 109954 Reducer R1/4 male x G1/4 female

1 x 104840 Reducer M10x1 male x G1/4 female

安装配件组套CLASSIC, FUTURA, FLEX, NOVA标准载荷2点网挂含 2 米软

商品号: 110073

1 x 109690 Bracket cage hanger 2-point G1/4 female

2 x 113972 Purge connection with manual valve R1/4 male x G1/4 female

2 x 109849 Angle 90° R1/4 male x G1/4 female

4 x 101554 Hose connector G1/4 male for hose iØ 9.5 mm

2 m 101555 Heavy Duty hose

0,25 m 109695 Hose spiral guard 25 mm

2 x 109953 Reducer R1/8 male x G1/4 female

2 x 109954 Reducer R1/4 male x G1/4 female

2 x 104840 Reducer M10x1 male x G1/4 female

附件及安装配件组套STAR标准载荷

附件套件和安装套件STAR标准负载专门设计用于在正常环境条件下运行。套件包含所有必要的零件，包括每个润滑点的转换接头M10X1和G1/8。与附件套件不同，安装套件已包含软管。

梁夹安装

附件及安装套件STAR标准载荷1点65 mm梁夹安装包含 3 米软管

商品号: 116961

附件及安装套件STAR标准载荷2点65 mm梁夹安装包含 5 米软管

商品号: 116963

附件及安装套件STAR标准载荷1点65 mm梁夹安装不含软管

商品号: 116951

附件及安装套件STAR标准载荷2点65 mm梁夹安装不含软管

商品号: 116953

网挂安装

附件及安装套件STAR标准载荷1点网挂安装包含 3 米软管

商品号: 116962

附件及安装套件STAR标准载荷2点网挂安装包含 5 米软管

商品号: 116964

附件及安装套件STAR标准载荷1点网挂安装不含软管

商品号: 116952

附件及安装套件STAR标准载荷2点网挂安装不含软管

商品号: 116954

附件及安装配件组套STAR重载

附件套件和安装套件Star 重载专门设计用于环境条件恶劣的操作区域。该套件包含所有必要的零件，包括一个重载保护帽、一个带手动阀的吹扫接头和转换接头M10X1和G1/8。与附件套件不同，安装套件已包含软管。

梁夹安装

附件及安装套件STAR重载1点65 mm梁夹安装包含3米软管

商品号: 116965

附件及安装套件STAR重载2点65 mm梁夹安装包含 5 米软管

商品号: 116967

附件及安装套件STAR重载1点65 mm梁夹安装不含软管

商品号: 116955

附件及安装套件STAR重载2点65 mm梁夹安装不含软管

商品号: 116957

网挂安装

附件及安装套件STAR重载1点网挂安装包含 3 米软管

商品号: 116966

附件及安装套件STAR重载2点网挂安装包含 5 米软管

商品号: 116968

附件及安装套件STAR重载1点网挂安装不含软管

商品号: 116956

附件及安装套件STAR重载2点网挂安装不含软管

商品号: 116958

安装配件组套STAR标准载荷

梁夹安装

安装套件STAR标准载荷1点30 mm梁夹安装包含 2 米软管

商品号: 110074

1 x 109663 Bracket STAR Standard Duty 1-point G1/4 female

1 x 109420 Support flange STAR G1/4 male x G1/4 female

1 x 108606 Cover clip for protection cap STAR

1 x 109999 Protection cap STAR VARIO Heavy Duty 250

2 x 109957 Beam clamp 30 mm

1 x 113972 Purge connection with manual valve R1/4 male x G1/4 female

1 x 109849 Angle 90° R1/4 male x G1/4 female

2 x 101554 Hose connector G1/4 male for hose iØ 9.5 mm

2 m 101555 Heavy Duty hose

1 x 109953 Reducer R1/8 male x G1/4 female

1 x 109954 Reducer R1/4 male x G1/4 female

1 x 104840 Reducer M10x1 male x G1/4 female

安装套件STAR标准载荷1点65 mm梁夹安装包含 2 米软管

商品号: 110075

1 x 109663 Bracket STAR Standard Duty 1-point G1/4 female

1 x 109420 Support flange STAR G1/4 male x G1/4 female

1 x 108606 Cover clip for protection cap STAR

1 x 109999 Protection cap STAR VARIO Heavy Duty 250

2 x 109958 Beam clamp 65 mm

1 x 113972 Purge connection with manual valve R1/4 male x G1/4 female

1 x 109849 Angle 90° R1/4 male x G1/4 female

2 x 101554 Hose connector G1/4 male for hose iØ 9.5 mm

2 m 101555 Heavy Duty hose

1 x 109953 Reducer R1/8 male x G1/4 female

1 x 109954 Reducer R1/4 male x G1/4 female

1 x 104840 Reducer M10x1 male x G1/4 female

安装套件STAR标准载荷2点30 mm梁夹安装包含 4 米软管

商品号: 110076

1 x 109667 Bracket STAR Standard Duty 2-point G1/4 female

2 x 109420 Support flange STAR G1/4 male x G1/4 female

2 x 108606 Cover clip for protection cap STAR

2 x 109999 Protection cap STAR VARIO Heavy Duty 250

2 x 109957 Beam clamp 30 mm

2 x 113972 Purge connection with manual valve R1/4 male x G1/4 female

2 x 109849 Angle 90° R1/4 male x G1/4 female

4 x 101554 Hose connector G1/4 male for hose iØ 9.5 mm

4 m 101555 Heavy Duty hose

0,5 m 109695 Hose spiral guard 25 mm

2 x 109953 Reducer R1/8 male x G1/4 female

2 x 109954 Reducer R1/4 male x G1/4 female

2 x 104840 Reducer M10x1 male x G1/4 female

安装套件STAR标准载荷2点65 mm梁夹安装包含 4 米软管

商品号: 110077

1 x 109667 Bracket STAR Standard Duty 2-point G1/4 female

2 x 109420 Support flange STAR G1/4 male x G1/4 female

2 x 108606 Cover clip for protection cap STAR

2 x 109999 Protection cap STAR VARIO Heavy Duty 250

2 x 109958 Beam clamp 65 mm

2 x 113972 Purge connection with manual valve R1/4 male x G1/4 female

2 x 109849 Angle 90° R1/4 male x G1/4 female

4 x 101554 Hose connector G1/4 male for hose iØ 9.5 mm

4 m 101555 Heavy Duty hose

0,5 m Hose spiral guard 25 mm

2 x 109953 Reducer R1/8 male x G1/4 female

2 x 109954 Reducer R1/4 male x G1/4 female

2 x 104840 Reducer M10x1 male x G1/4 female

安装套件STAR标准载荷3点30 mm梁夹安装包含 6 米软管

商品号: 110078

1 x 109670 Bracket STAR Standard Duty 3-point G1/4 female

3 x 109420 Support flange STAR G1/4 male x G1/4 female

3 x 108606 Cover clip for protection cap STAR

3 x 109999 Protection cap STAR VARIO Heavy Duty 250

2 x 109957 Beam clamp 30 mm

3 x 113972 Purge connection with manual valve R1/4 male x G1/4 female

3 x 109849 Angle 90° R1/4 male x G1/4 female

6 x 101554 Hose connector G1/4 male for hose iØ 9.5 mm

6 m 101555 Heavy Duty hose

0,5 m 109695 Hose spiral guard 25 mm

3 x 109953 Reducer R1/8 male x G1/4 female

3 x 109954 Reducer R1/4 male x G1/4 female

3 x 104840 Reducer M10x1 male x G1/4 female

安装套件STAR标准载荷3点65 mm梁夹安装包含 6 米软管

商品号: 110079

1 x 109670 Bracket STAR Standard Duty 3-point G1/4 female

3 x 109420 Support flange STAR G1/4 male x G1/4 female

3 x 108606 Cover clip for protection cap STAR

3 x 109999 Protection cap STAR VARIO Heavy Duty 250

2 x 109958 Beam clamp 65 mm

3 x 113972 Purge connection with manual valve R1/4 male x G1/4 female

3 x 109849 Angle 90° R1/4 male x G1/4 female

6 x 101554 Hose connector G1/4 male for hose iØ 9.5 mm

6 m 101555 Heavy Duty hose

0,5 m Hose spiral guard 25 mm

3 x 109953 Reducer R1/8 male x G1/4 female

3 x 109954 Reducer R1/4 male x G1/4 female

3 x 104840 Reducer M10x1 male x G1/4 female

安装套件STAR标准载荷4点30 mm梁夹安装包含 8 米软管

商品号: 110080

1 x 109673 Bracket STAR Standard Duty 4-point G1/4 female

4 x 109420 Support flange STAR G1/4 male x G1/4 female

4 x 108606 Cover clip for protection cap STAR

4 x 109999 Protection cap STAR VARIO Heavy Duty 250

2 x 109957 Beam clamp 30 mm

4 x 113972 Purge connection with manual valve R1/4 male x G1/4 female

4 x 109849 Angle 90° R1/4 male x G1/4 female

8 x 101554 Hose connector G1/4 male for hose iØ 9.5 mm

8 m 101555 Heavy Duty hose

0,5 m 109695 Hose spiral guard 25 mm

4 x 109953 Reducer R1/8 male x G1/4 female

4 x 109954 Reducer R1/4 male x G1/4 female

4 x 104840 Reducer M10x1 male x G1/4 female

安装套件STAR标准载荷4点65 mm梁夹安装包含 8 米软管

商品号: 110081

1 x 109673 Bracket STAR Standard Duty 4-point G1/4 female

4 x 109420 Support flange STAR G1/4 male x G1/4 female

4 x 108606 Cover clip for protection cap STAR

4 x 109999 Protection cap STAR VARIO Heavy Duty 250

2 x 109958 Beam clamp 65 mm

4 x 113972 Purge connection with manual valve R1/4 male x G1/4 female

4 x 109849 Angle 90° R1/4 male x G1/4 female

8 x 101554 Hose connector G1/4 male for hose iØ 9.5 mm

8 m 101555 Heavy Duty hose

0,5 m Hose spiral guard 25 mm

4 x 109953 Reducer R1/8 male x G1/4 female

4 x 109954 Reducer R1/4 male x G1/4 female

4 x 104840 Reducer M10x1 male x G1/4 female

安装配件组套STAR重载

梁夹安装

安装套件STAR重载1点30 mm梁夹安装包含2米软管

商品号: 110082

1 x 109664 Bracket STAR Heavy Duty C-section 1-point G1/4 female

1 x 109420 Support flange STAR G1/4 male x G1/4 female

1 x 108606 Cover clip for protection cap STAR

1 x 109999 Protection cap STAR VARIO Heavy Duty 250

2 x 109957 Beam clamp 30 mm

1 x 113972 Purge connection with manual valve R1/4 male x G1/4 female

1 x 109849 Angle 90° R1/4 male x G1/4 female

2 x 101554 Hose connector G1/4 male for hose iØ 9.5 mm

2 m 101555 Heavy Duty hose

1 x 109953 Reducer R1/8 male x G1/4 female

1 x 109954 Reducer R1/4 male x G1/4 female

1 x 104840 Reducer M10x1 male x G1/4 female

安装套件STAR重载1点65 mm梁夹安装包含 2 米软管

商品号: 110083

1 x 109664 Bracket STAR Heavy Duty C-section 1-point G1/4 female

1 x 109420 Support flange STAR G1/4 male x G1/4 female

1 x 108606 Cover clip for protection cap STAR

1 x 109999 Protection cap STAR VARIO Heavy Duty 250

2 x 109958 Beam clamp 65 mm

1 x 113972 Purge connection with manual valve R1/4 male x G1/4 female

1 x 109849 Angle 90° R1/4 male x G1/4 female

2 x 101554 Hose connector G1/4 male for hose iØ 9.5 mm

2 m 101555 Heavy Duty hose

1 x 109953 Reducer R1/8 male x G1/4 female

1 x 109954 Reducer R1/4 male x G1/4 female

1 x 104840 Reducer M10x1 male x G1/4 female

安装套件STAR重载2点30 mm梁夹安装包含 4 米软管

商品号: 110084

1 x 108648 Bracket STAR Heavy Duty C-section 2-point G1/4 female

2 x 109420 Support flange STAR G1/4 male x G1/4 female

2 x 108606 Cover clip for protection cap STAR

2 x 109999 Protection cap STAR VARIO Heavy Duty 250

2 x 109957 Beam clamp 30 mm

2 x 113972 Purge connection with manual valve R1/4 male x G1/4 female

2 x 109849 Angle 90° R1/4 male x G1/4 female

4 x 101554 Hose connector G1/4 male for hose iØ 9.5 mm

4 m 101555 Heavy Duty hose

0,5 m 109695 Hose spiral guard 25 mm

2 x 109953 Reducer R1/8 male x G1/4 female

2 x 109954 Reducer R1/4 male x G1/4 female

2 x 104840 Reducer M10x1 male x G1/4 female

安装套件STAR重载2点65 mm梁夹安装包含 4 米软管

商品号: 110085

1 x 108648 Bracket STAR Heavy Duty C-section 2-point G1/4 female

2 x 109420 Support flange STAR G1/4 male x G1/4 female

2 x 108606 Cover clip for protection cap STAR

2 x 109999 Protection cap STAR VARIO Heavy Duty 250

2 x 109958 Beam clamp 65 mm

2 x 113972 Purge connection with manual valve R1/4 male x G1/4 female

2 x 109849 Angle 90° R1/4 male x G1/4 female

4 x 101554 Hose connector G1/4 male for hose iØ 9.5 mm

4 m 101555 Heavy Duty hose

0,5 m Hose spiral guard 25 mm

2 x 109953 Reducer R1/8 male x G1/4 female

2 x 109954 Reducer R1/4 male x G1/4 female

2 x 104840 Reducer M10x1 male x G1/4 female

安装套件STAR重载3点30 mm梁夹安装包含 6 米软管

商品号: 110086

1 x 109671 Bracket STAR Heavy Duty C-section 3-point G1/4 female

3 x 109420 Support flange STAR G1/4 male x G1/4 female

3 x 108606 Cover clip for protection cap STAR

3 x 109999 Protection cap STAR VARIO Heavy Duty 250

2 x 109957 Beam clamp 30 mm

3 x 113972 Purge connection with manual valve R1/4 male x G1/4 female

3 x 109849 Angle 90° R1/4 male x G1/4 female

6 x 101554 Hose connector G1/4 male for hose iØ 9.5 mm

6 m 101555 Heavy Duty hose

0,5 m 109695 Hose spiral guard 25 mm

3 x 109953 Reducer R1/8 male x G1/4 female

3 x 109954 Reducer R1/4 male x G1/4 female

3 x 104840 Reducer M10x1 male x G1/4 female

安装套件STAR重载3点65 mm梁夹安装包含 6 米软管

商品号: 110087

1 x 109671 Bracket STAR Heavy Duty C-section 3-point G1/4 female

3 x 109420 Support flange STAR G1/4 male x G1/4 female

3 x 108606 Cover clip for protection cap STAR

3 x 109999 Protection cap STAR VARIO Heavy Duty 250

2 x 109958 Beam clamp 65 mm

3 x 113972 Purge connection with manual valve R1/4 male x G1/4 female

3 x 109849 Angle 90° R1/4 male x G1/4 female

6 x 101554 Hose connector G1/4 male for hose iØ 9.5 mm

6 m 101555 Heavy Duty hose

0,5 m 109695 Hose spiral guard 25 mm

3 x 109953 Reducer R1/8 male x G1/4 female

3 x 109954 Reducer R1/4 male x G1/4 female

3 x 104840 Reducer M10x1 male x G1/4 female

安装套件STAR重载4点30 mm梁夹安装包含 8 米软管

商品号: 110088

1 x 109674 Bracket STAR Heavy Duty C-section 4-point G1/4 female

4 x 109420 Support flange STAR G1/4 male x G1/4 female

4 x 108606 Cover clip for protection cap STAR

4 x 109999 Protection cap STAR VARIO Heavy Duty 250

2 x 109957 Beam clamp 30 mm

4 x 113972 Purge connection with manual valve R1/4 male x G1/4 female

4 x 109849 Angle 90° R1/4 male x G1/4 female

4 x 101554 Hose connector G1/4 male for hose iØ 9.5 mm

8 m 101555 Heavy Duty hose

0,5 m 109695 Hose spiral guard 25 mm

4 x 109953 Reducer R1/8 male x G1/4 female

4 x 109954 Reducer R1/4 male x G1/4 female

4 x 104840 Reducer M10x1 male x G1/4 female

安装套件STAR重载4点65 mm梁夹安装包含 8 米软管

商品号: 110089

1 x 109674 Bracket STAR Heavy Duty C-section 4-point G1/4 female

4 x 109420 Support flange STAR G1/4 male x G1/4 female

4 x 108606 Cover clip for protection cap STAR

4 x 109999 Protection cap STAR VARIO Heavy Duty 250

2 x 109958 Beam clamp 65 mm

4 x 113972 Purge connection with manual valve R1/4 male x G1/4 female

4 x 109849 Angle 90° R1/4 male x G1/4 female

4 x 101554 Hose connector G1/4 male for hose iØ 9.5 mm

8 m 101555 Heavy Duty hose

0,5 m 109695 Hose spiral guard 25 mm

4 x 109953 Reducer R1/8 male x G1/4 female

4 x 109954 Reducer R1/4 male x G1/4 female

4 x 104840 Reducer M10x1 male x G1/4 female

安装配件组套STAR标准载荷

网挂安装

安装套件STAR标准载荷1点网挂安装包含 2 米软管

商品号: 110090

1 x 109665 Bracket STAR Standard Duty cage hanger 1-point G1/4 female

1 x 109420 Support flange STAR G1/4 male x G1/4 female

1 x 108606 Cover clip for protection cap STAR

1 x 109999 Protection cap STAR VARIO Heavy Duty 250

1 x 113972 Purge connection with manual valve R1/4 male x G1/4 female

1 x 109849 Angle 90° R1/4 male x G1/4 female

2 x 101554 Hose connector G1/4 male for hose iØ 9.5 mm

2 m 101555 Heavy Duty hose

1 x 109953 Reducer R1/8 male x G1/4 female

1 x 109954 Reducer R1/4 male x G1/4 female

1 x 104840 Reducer M10x1 male x G1/4 female

安装套件STAR标准载荷2点网挂安装包含 4 米软管

商品号: 110091

1 x 109668 Bracket STAR Standard Duty cage hanger 2-point G1/4 female

2 x 109420 Support flange STAR G1/4 male x G1/4 female

2 x 108606 Cover clip for protection cap STAR

2 x 109999 Protection cap STAR VARIO Heavy Duty 250

2 x 113972 Purge connection with manual valve R1/4 male x G1/4 female

2 x 109849 Angle 90° R1/4 male x G1/4 female

4 x 101554 Hose connector G1/4 male for hose iØ 9.5 mm

4 m 101555 Heavy Duty hose

0,5 m Hose spiral guard 25 mm

2 x 109953 Reducer R1/8 male x G1/4 female

2 x 109954 Reducer R1/4 male x G1/4 female

2 x 104840 Reducer M10x1 male x G1/4 female

安装套件STAR标准载荷3点网挂安装包含 6 米软管

商品号: 110092

1 x Bracket STAR Standard Duty cage hanger 3-point G1/4 female

3 x 109420 Support flange STAR G1/4 male x G1/4 female

3 x 108606 Cover clip for protection cap STAR

3 x 109999 Protection cap STAR VARIO Heavy Duty 250

3 x 113972 Purge connection with manual valve R1/4 male x G1/4 female

3 x 109849 Angle 90° R1/4 male x G1/4 female

6 x 101554 Hose connector G1/4 male for hose iØ 9.5 mm

6 m 101555 Heavy Duty hose

0,5 m Hose spiral guard 25 mm

3 x 109953 Reducer R1/8 male x G1/4 female

3 x 109954 Reducer R1/4 male x G1/4 female

3 x 104840 Reducer M10x1 male x G1/4 female

安装套件STAR标准载荷4点网挂安装包含 8 米软管

商品号: 110093

1 x Bracket STAR Standard Duty cage hanger 4-point G1/4 female

4 x 109420 Support flange STAR G1/4 male x G1/4 female

4 x 108606 Cover clip for protection cap STAR

4 x 109999 Protection cap STAR VARIO Heavy Duty 250

4 x 113972 Purge connection with manual valve R1/4 male x G1/4 female

4 x 109849 Angle 90° R1/4 male x G1/4 female

8 x 101554 Hose connector G1/4 male for hose iØ 9.5 mm

8 m 101555 Heavy Duty hose

0,5 m Hose spiral guard 25 mm

4 x 109953 Reducer R1/8 male x G1/4 female

4 x 109954 Reducer R1/4 male x G1/4 female

4 x 104840 Reducer M10x1 male x G1/4 female

安装配件组套STAR重载

网挂安装

安装套件STAR重载1点网挂安装包含 2 米软管

商品号: 110094

1 x 109664 Bracket STAR Heavy Duty C-section 1-point G1/4 female

1 x 109420 Support flange STAR G1/4 male x G1/4 female

1 x 108606 Cover clip for protection cap STAR

1 x 109999 Protection cap STAR VARIO Heavy Duty 250

2 x 109959 Cage hanger arm

1 x 113972 Purge connection with manual valve R1/4 male x G1/4 female

1 x 109849 Angle 90° R1/4 male x G1/4 female

2 x 101554 Hose connector G1/4 male for hose iØ 9.5 mm

2 m 101555 Heavy Duty hose

1 x 109953 Reducer R1/8 male x G1/4 female

1 x 109954 Reducer R1/4 male x G1/4 female

1 x 104840 Reducer M10x1 male x G1/4 female

安装套件STAR重载2点网挂安装包含 4 米软管

商品号: 110095

1 x 108648 Bracket STAR Heavy Duty C-section 2-point G1/4 female

2 x 109420 Support flange STAR G1/4 male x G1/4 female

2 x 108606 Cover clip for protection cap STAR

2 x 109999 Protection cap STAR VARIO Heavy Duty 250

2 x 109959 Cage hanger arm

2 x 113972 Purge connection with manual valve R1/4 male x G1/4 female

2 x 109849 Angle 90° R1/4 male x G1/4 female

4 x 101554 Hose connector G1/4 male for hose iØ 9.5 mm

4 m 101555 Heavy Duty hose

0,5 m Hose spiral guard 25 mm

2 x 109953 Reducer R1/8 male x G1/4 female

2 x 109954 Reducer R1/4 male x G1/4 female

2 x 104840 Reducer M10x1 male x G1/4 female

安装套件STAR重载3点网挂安装包含 6 米软管

商品号: 110096

1 x 109671 Bracket STAR Heavy Duty C-section 3-point G1/4 female

3 x 109420 Support flange STAR G1/4 male x G1/4 female

3 x 108606 Cover clip for protection cap STAR

3 x 109999 Protection cap STAR VARIO Heavy Duty 250

2 x 109959 Cage hanger arm

3 x 113972 Purge connection with manual valve R1/4 male x G1/4 female

3 x 109849 Angle 90° R1/4 male x G1/4 female

6 x 101554 Hose connector G1/4 male for hose iØ 9.5 mm

6 m 101555 Heavy Duty hose

0,5 m 109695 Hose spiral guard 25 mm

3 x 109953 Reducer R1/8 male x G1/4 female

3 x 109954 Reducer R1/4 male x G1/4 female

3 x 104840 Reducer M10x1 male x G1/4 female

安装套件STAR重载4点网挂安装包含 8 米软管

商品号: 110097

1 x 109674 Bracket STAR Heavy Duty C-section 4-point G1/4 female

4 x 109420 Support flange STAR G1/4 male x G1/4 female

4 x 108606 Cover clip for protection cap STAR

4 x 109999 Protection cap STAR VARIO Heavy Duty 250

2 x 109959 Cage hanger arm

4 x 113972 Purge connection with manual valve R1/4 male x G1/4 female

4 x 109849 Angle 90° R1/4 male x G1/4 female

4 x 101554 Hose connector G1/4 male for hose iØ 9.5 mm

8 m 101555 Heavy Duty hose

0,5 m 109695 Hose spiral guard 25 mm

4 x 109953 Reducer R1/8 male x G1/4 female

4 x 109954 Reducer R1/4 male x G1/4 female

4 x 104840 Reducer M10x1 male x G1/4 female

安装配件组套STAR轨道安装

安装套件STAR 1点轨道安装包含 2 米软管

商品号: 110098

1 x 110014 Bracket STAR rail mount 1-point G1/4 female

1 x 109420 Support flange STAR G1/4 male x G1/4 female

1 x 108606 Cover clip for protection cap STAR

1 x 109999 Protection cap STAR VARIO Heavy Duty 250

1 x 113972 Purge connection with manual valve R1/4 male x G1/4 female

1 x 109849 Angle 90° R1/4 male x G1/4 female

2 x 101554 Hose connector G1/4 male for hose iØ 9.5 mm

2 m 101555 Heavy Duty hose

1 x 109953 Reducer R1/8 male x G1/4 female

1 x 109954 Reducer R1/4 male x G1/4 female

1 x 104840 Reducer M10x1 male x G1/4 female

安装套件STAR 2点轨道安装包含 4 米软管

商品号: 110099

1 x 110015 Bracket STAR rail mount 2-point G1/4 female

2 x 109420 Support flange STAR G1/4 male x G1/4 female

2 x 108606 Cover clip for protection cap STAR

2 x 109999 Protection cap STAR VARIO Heavy Duty 250

2 x 113972 Purge connection with manual valve R1/4 male x G1/4 female

2 x 109849 Angle 90° R1/4 male x G1/4 female

4 x 101554 Hose connector G1/4 male for hose iØ 9.5 mm

4 m 101555 Heavy Duty hose

0,5 m Hose spiral guard 25 mm

2 x 109953 Reducer R1/8 male x G1/4 female

2 x 109954 Reducer R1/4 male x G1/4 female

2 x 104840 Reducer M10x1 male x G1/4 female

安装套件STAR 3点轨道安装包含 6 米软管

商品号: 110100

1 x 110016 Bracket STAR rail mount 3-point G1/4 female

3 x 109420 Support flange STAR G1/4 male x G1/4 female

3 x 108606 Cover clip for protection cap STAR

3 x 109999 Protection cap STAR VARIO Heavy Duty 250

3 x 113972 Purge connection with manual valve R1/4 male x G1/4 female

3 x 109849 Angle 90° R1/4 male x G1/4 female

6 x 101554 Hose connector G1/4 male for hose iØ 9.5 mm

6 m 101555 Heavy Duty hose

0,5 m Hose spiral guard 25 mm

3 x 109953 Reducer R1/8 male x G1/4 female

3 x 109954 Reducer R1/4 male x G1/4 female

3 x 104840 Reducer M10x1 male x G1/4 female

安装套件STAR 4点轨道安装包含 8 米软管

商品号: 110101

1 x 110017 Bracket STAR rail mount 4-point G1/4 female

4 x 109420 Support flange STAR G1/4 male x G1/4 female

4 x 108606 Cover clip for protection cap STAR

4 x 109999 Protection cap STAR VARIO Heavy Duty 250

4 x 113972 Purge connection with manual valve R1/4 male x G1/4 female

4 x 109849 Angle 90° R1/4 male x G1/4 female

4 x 101554 Hose connector G1/4 male for hose iØ 9.5 mm

8 m 101555 Heavy Duty hose

0,5 m Hose spiral guard 25 mm

4 x 109953 Reducer R1/8 male x G1/4 female

4 x 109954 Reducer R1/4 male x G1/4 female

4 x 104840 Reducer M10x1 male x G1/4 female

配件组套ULTRA

配件组套ULTRA标准载荷1点65mm梁夹安装不含软管

商品号: 116335

1 x Mounting bracket ULTRA

2 x Beam clamp 65 mm

2 x Hose connector 9/16"-18 UNFi JIC male with union nut for Extreme Heavy Duty hose oØ 16 mm

2 x Hexagon-nipple 9/16 JIC male x R1/4 male straight for tube connection

1 x Reducer G1/8 male x G1/4 female

1 x Reducer M10x1 male x G1/4 female

1 x Angle 90° R1/4 male x 9/16 JIC male

配件组套ULTRA标准载荷1点网挂安装不含软管

商品号: 116336

1 x Mounting bracket ULTRA

2 x Cage hanger arm

2 x Hose connector 9/16"-18 UNFi JIC male with union nut for Extreme Heavy Duty hose oØ 16 mm

2 x Hexagon-nipple 9/16 JIC male x R1/4 male straight for tube connection

1 x Reducer G1/8 male x G1/4 female

1 x Reducer M10x1 male x G1/4 female

1 x Angle 90° R1/4 male x 9/16 JIC male

配件组套ULTRA重载1点65mm梁夹安装不含软管

商品号: 116337

1 x Mounting bracket ULTRA

1 x Protection cap ULTRA Heavy Duty

2 x Beam clamp 65 mm

1 x T-Adapter 2 x G1/4 female x R1/4 male

1 x Hydraulic-type lubricating nipple R1/4

2 x Hose connector 9/16"-18 UNFi JIC male with union nut for Extreme Heavy Duty hose oØ 16 mm

2 x Hexagon-nipple 9/16 JIC male x R1/4 male straight for tube connection

1 x Reducer G1/8 male x G1/4 female

1 x Reducer M10x1 male x G1/4 female

1 x Angle 90° R1/4 male x 9/16 JIC male

配件组套ULTRA重载1点网挂安装不含软管

商品号: 116338

1 x Mounting bracket ULTRA

1 x Protection cap ULTRA Heavy Duty

2 x Cage hanger arm

1 x T-Adapter 2 x G1/4 female x R1/4 male

1 x Hydraulic-type lubricating nipple R1/4

2 x Hose connector 9/16"-18 UNFi JIC male with union nut for Extreme Heavy Duty hose oØ 16 mm

2 x Hexagon-nipple 9/16 JIC male x R1/4 male straight for tube connection

1 x Reducer G1/8 male x G1/4 female

1 x Reducer M10x1 male x G1/4 female

1 x Angle 90° R1/4 male x 9/16 JIC male

安装组套ULTRA

安装组套ULTRA标准载荷1点65mm梁夹安装含 5 米软管

商品号: 116339

1 x Mounting bracket ULTRA

2 x Beam clamp 65 mm

5 m Extreme Heavy Duty hose up to +100 °C oØ 11.8 mm x iØ 6.4 mm

2 x Hose connector 9/16"-18 UNFi JIC male with union nut for Extreme Heavy Duty hose oØ 16 mm

2 x Hexagon-nipple 9/16 JIC male x R1/4 male straight for tube connection

1 x Reducer G1/8 male x G1/4 female

1 x Reducer M10x1 male x G1/4 female

1 x Angle 90° R1/4 male x 9/16 JIC male

安装组套ULTRA标准载荷1点网挂安装含 5 米软管

商品号: 116340

1 x Mounting bracket ULTRA

2 x Cage hanger arm

5 m Extreme Heavy Duty hose up to +100 °C oØ 11.8 mm x iØ 6.4 mm

2 x Hose connector 9/16"-18 UNFi JIC male with union nut for Extreme Heavy Duty hose oØ 16 mm

2 x Hexagon-nipple 9/16 JIC male x R1/4 male straight for tube connection

1 x Reducer G1/8 male x G1/4 female

1 x Reducer M10x1 male x G1/4 female

1 x Angle 90° R1/4 male x 9/16 JIC male

安装组套ULTRA重载1点65mm梁夹安装含 5 米软管

商品号: 116341

1 x Mounting bracket ULTRA

1 x Protection cap ULTRA Heavy Duty

5 m Extreme Heavy Duty hose up to +100 °C oØ 11.8 mm x iØ 6.4 mm

2 x Beam clamp 65 mm

1 x T-Adapter 2 x G1/4 female x R1/4 male

1 x Hydraulic-type lubricating nipple R1/4

2 x Hose connector 9/16"-18 UNFi JIC male with union nut for Extreme Heavy Duty hose oØ 16 mm

2 x Hexagon-nipple 9/16 JIC male x R1/4 male straight for tube connection

1 x Reducer G1/8 male x G1/4 female

1 x Reducer M10x1 male x G1/4 female

1 x Angle 90° R1/4 male x 9/16 JIC male

安装组套ULTRA重载1点网挂安装含 5 米软管

商品号: 116342

1 x Mounting bracket ULTRA

1 x Protection cap ULTRA Heavy Duty

5 m Extreme Heavy Duty hose up to +100 °C oØ 11.8 mm x iØ 6.4 mm

2 x Cage hanger arm

1 x T-Adapter 2 x G1/4 female x R1/4 male

1 x Hydraulic-type lubricating nipple R1/4

2 x Hose connector 9/16"-18 UNFi JIC male with union nut for Extreme Heavy Duty hose oØ 16 mm

2 x Hexagon-nipple 9/16 JIC male x R1/4 male straight for tube connection

1 x Reducer G1/8 male x G1/4 female

1 x Reducer M10x1 male x G1/4 female

1 x Angle 90° R1/4 male x 9/16 JIC male
